4 Revit Fixture-Room Layout Tips | ADA-Universal Design Review

Posted by Daniel Hughes on Jun 30, 2016 11:00:00 AM

Consider using these four tips\processes; while creating manufacturer product Revit families and to assist with the design \ layout of these space types:

  • toilet rooms, locker rooms, washrooms

  • commercial kitchens & food service

  • mechanical & utility rooms

  • office, retail, education & healthcare space w/ furniture, fixtures & equipment

--- Revit for Restaurant Prototypes | Core Business-Design Values ---

1) Revit Family Reference Planes Aid Dimensioning

The image on the left is a front view of a Bradley solid surface lavatory Revit family.

  1. The PLAN & FRONT ELEVATION images on the right; show the lavatory family installed into a Revit project.
  2. The lavatory Revit family (on the left) embeds vertical and horizontal Reference Planes (green dashed lines); that define the vertical \ horizontal surfaces or center lines of lavatory components.
  3. Tip: This includes Water & waste connections, electrical, faucet & soap dispenser placement, lavatory structural support and installation height locations.
  4. Images on the right (above), show dimensions often used in PLAN\ELEVATION view in architectural, plumbing and/or contractor drawings.
  5. Reference planes in the Revit Family are set to WEAK Reference; thereby allowing the Revit Project to dimension these locations.
Read More

Topics: wheelchair knee toe clearance, revit for locker room design, revit ada clearance box, revit for toilet, revit for university design, Revit Training-Education, revit ada toe knee clearance box, revit reference planes, how to implement revit, revit for ADA review, revit for toilet room design

Revit Reference Planes Define ADA-Installation Mounting Heights-Clearances

Posted by Daniel Hughes on Oct 3, 2011 10:22:24 AM

When you open a Bradley Revit family, like the Bradley Verge Lavatory System, you will see more than a dozen green dashed lines. These are Revit Reference Planes.

Read More

Topics: Bradley Revit-BIM FAQs, americans with disabilities act, bradley verge lavatory system, download free revit family library, Revit Help-Technical Support, Bradley Plumbing Fixture Revit Family, revit reference planes, autodesk revit, revit dimensions, revit clearance box, revit lavatory sink family, ada clearance installation height
